Basic Information
Brand
Walton
model
WSI-OCEANUS-18M
series name
Oceanus
air conditioner type
Intelligent Inverter
function
Cooling

cooling capacity (ton)
1.5 Ton
compressor
Rotary (Inverter)
refrigerant
R-32
technology
Latest Intelligent INVERTER
cooling capacity (btu/hr)
18000 BTU/Hr
cooling capacity (w)
5275 Watts
rated voltage
230V ~ 50Hz

rated power
1670
rated current (a)
7.21
eer
3.16
Detailed Information
refrigerant amount (kg)
0.47
operating range (ambient temperature)
20˚C to 55˚C
evaporator fin type
Louvered Fin
condenser type
Copper Tube Condenser
condenser fin type
Louvered Fin
maximum pipe length
10m
turbo mode (maximum cooling)
Yes
eco mode
Yes
dry mode
Yes
auto operation
Yes
auto restart
Yes
fan mode
Yes
speed setting
Yes (Auto, High, Medium, Low)
comfort cooling
Yes
timer
Yes
sleep
Yes
Health Mode
Yes
display type
LCD
operation/control
Via IR (Infrared Ray)
child lock
Yes
temperature unit change
Yes (16​°C to 31°C)
auto up-down swing
Yes
auto left-right swing
Yes
indoor dimensions (mm) [l×w×h]
Unit: 947 x 321 x 235, Packing: 1025 x 400 x 300
outdoor dimensions (mm) [l×w×h]:
Unit: 844 x 310 x 546, Packing: 900 x 372 x 610
net weight (indoor) (kg)
12.5 ± 0.5
gross weight (indoor) (kg)
15 ± 0.5
net weight (outdoor) (kg)
24 ± 1
gross weight (outdoor) (kg)
28.5 ± 1
Special Feature
special features
1. Frost Clean: Frost Clean Removes dirt from the evaporator, Keeps evaporator dry and fungus free, Prevents the growth of harmful microorganism, Increases longevity of Air Conditioner

Step 1: Ice Formation Turn on the frost clean function by remote controller, evaporator will cool down quickly and frost the condensed water on the surface of evaporator including the dust

Step 2: Defrosting & Auto Cleaning The condensed water including dust will defrost automatically from the evaporator surface and washed away due to high-speed rotation of blower fan as compressor is turned off.

Step 3: Drying Up The evaporator is finally dried up by the blower fan to prevent the growth of mildew.

2. FAST COOLING: Walton Intelligent Inverter Air Conditioner offers faster cooling for the special combination of the compressor and control board. Only press the "Turbo" button and enjoy the feature.

3. BUILT-IN SURGE PROTECTION: The integrated surge protector in Walton Air Conditioners shield the sensitive circuits from unexpected power surges (2kV and 4kV)*, allowing you to enjoy worry-free & hassle-free cooling throughout the year.

4. ECO FRIENDLY: Walton Intelligent Inverter Air Conditioner uses R32 gas as refrigerant which is environment friendly. R32 refrigerant has Zero Ozone Depletion Potential (ODP) & very low Global Warming Potential Ratings (GWP).

5. SILENT OPERATION: Walton Intelligent Inverter Air Conditioner has much quieter and smoother operation. Its indoor unit creates minimum amount of noise with a feel of natural cool breeze.

6. ENERGY SAVING: Walton Intelligent Inverter Air Conditioner has a unique feature named Economy. Just pressing a single button (ECO) will allow the unit to save maximum energy compared to typical non-inverter type air conditioner.

7. MULTI DIRECTIONAL AIR-FLOW: Walton Intelligent Inverter Air Conditioner has automated vertical and horizontal air swing which enable the air to guide at each and every corner of the room.

8. WIDE TEMPERATURE RANGE: The Walton Intelligent Inverter Air Conditioner features a wide indoor set temperature range of 16°C to 31°C, with an outdoor ambient temperature operating range of 20°C to 55°C.

9. WIDE WORKING VOLTAGE RANGE: Walton Intelligent Inverter Air Conditioner has a wide working voltage range starting from 130V to 280V AC at 50Hz.

Warranty Information
product replacement warranty
Guarantee: 1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)
residential use
Compressor Guarantee: 12 Years

Spare Parts Support: 3 Years

Inverter PCB Warranty: 3 years

After Sales Service: 1 Year (Free)

commercial use
Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions
Warranty Terms & Conditions
1. This warranty does not cover the following cases -

i) If the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced or modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated.

iii) Product defects due to incorrect or negligent storing or use of the products.

iv) Failure to start due to voltage conditions, blown fuses or other damage due to inadequacy or interruption of electrical service.

v) Product defects due to exposure to extreme conditions, e.g. thunder, lightning, water ingress, fire, obstacle to deliver indoor & outdoor airflow.

vi) Damage / failure of product due to rat, cockroach and insects attack etc.

vii) If unit installed in hazards environment by chemical fume, corrosive environment like acid solution, sulfur solution, hydrogen per oxide, sodium sulfate salt, hydrogen Sulfide, Chlorides, bleaching powder, ammonia, chlorine. IPA/Thinner etc.

viii) If unit install in kitchen/oily environment and any heat element/source very near to indoor and outdoor.

2. This warranty covers only manufacturing defects, subject to verification by company personnel.

3. After sales service will be applicable only at company authorized service points.

4. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice
